Hailea LED E Series Specifications
Hailea E25 Series
Dimensions: 47x25x28cm
Aquarium Volume: 25L
Filter Flow Rate: 200L/hr
Light Wattage: 5W
Power Requirements: 220 ~ 240V AC
Suitable: Coldwater, Tropical
Filtration:
Model - RP-200
Power - 3.5W
Qmax - 200L/h
Replacement Filter Cartridge:CA819
Hailea E40 Series
Dimensions: 47 x 25 x 42cm
Aquarium Volume: 40L
Filter Flow Rate: 200L/hr
Light Wattage: 7W
Power Requirements: 220 ~ 240V AC
Suitable: Coldwater, Tropical
Filtration:
Model - RP-200
Power - 3.5W
Qmax - 200L/h
Replacement Filter Cartridge:CA819
Hailea E60 Series
Dimensions: 58.5 x 32 x 42.5cm
Aquarium Volume: 60L
Filter Flow Rate: 400L/hr
Light Wattage: 10W
Power Requirements: 220 ~ 240V AC
Suitable: Coldwater, Tropical
Filtration:
Model - RP-400
Power - 6W
Qmax - 200-400L/h
Replacement Filter Cartridge: CA820
Hailea E80 Series
Dimensions: 65.1 x 31 x 53.3cm
Aquarium Volume: 80L
Filter Flow Rate: 540L/hr
Light Wattage: 12W
Power Requirements: 220 ~ 240V AC
Suitable: Coldwater, Tropical
Filtration:
Model - RP-500
Power - 7W
Qmax - 300-540L/h
Replacement Filter Cartridge:
Hailea E110 Series
Dimensions: 77.1 x 36 x 53.3cm
Aquarium Volume: 80L
Filter Flow Rate: 540L/hr
Light Wattage: 27W
Power Requirements: 220 ~ 240V AC
Suitable: Coldwater, Tropical
Filtration:
Model - RP-500
Power - 7W
Qmax - 300-540L/h
Replacement Filter Cartridge:
Trouble Shooting
Hailea LED E Series Aquarium
LIGHT UNIT DOES NOT WORK
- Ensure switch is in the on position on the top of the light unit.
- Check light is plugged into power supply and the
switch is on.
POWER HEAD WORKING BUT NO / SLOWWATER FLOW
- Check impeller is in good condition and replace if needed.
- Make sure water level in aquarium is above the power head. Please note the power head is a water proof unit.
- Clean impeller, power head and all inlet and outlet pipes.
- Check that the spray bar is inserted correctly with the end cap at the opposite end to the elbow
AQUARIUM POSSIBLY LEAKING
- Clean carbon cartridge as this can create an overflow.
- Make sure spray bar holes are pointed down onto the carbon cartridge.
- If an air stone is being used check it is not bubbling water over the rim of the aquarium if so turn the air pump down.
- Make sure the aquarium is sitting on a level surface.
- If it is a salt water aquarium remove any salt creep as it can drain water from the aquarium.
- Lift the lid and remove the filter unit from the top of the aquarium. Mark the water level. Remove any excess water that may be sitting on the edge of
the aquarium. Leave for an hour. - Remove the fish, decorations and gravel. Empty the aquarium and clean the glass DO NOT WASH
IN SOAP OR DETERGENT. Place a piece of newspaper on a flat level solid surface. Carefully fill
the aquarium ensuring not to spill any water on to the newspaper. Leave the aquarium for several hours and then inspect the newspaper for wet patches.
